3 HI Pinion Gear Box

Salient Features: -

• Torsionally Rigid Steel Fabricated Body Designed to Dampen Vibrations
• Double helical Gears made of En-9, En-19, or En-24 Quality Steel Forgings. Duly hardened and grinded.
• Amply Rated Bearings to work efficiently at Peak Loads
• Double Oil Seals fitted on Shaft extensions
• Lubrication lines for Bearings, and Oil Splash system for gears are provided.

Technical Specifications: -

• 3 Hi and 2 Hi Pinion Gear Boxes for Low Speed and High speed type
• 4 Hi Gear Boxes for Cold Rolling Mills
• Speed Increaser cum Pinion gear Boxes
• Gear Boxes suitable from 200 HP to 2000 HP Drives
• Gear Boxes suitable from 150 mm PCD to 600 mm PCD Mills
• Speed Range 50 R.P.M to 750 R.P.M
